모델명
|
HI 4522
|
|
측정범위
|
pH
|
-2.0 to 20.0; -2.00 to 20.00; -2.000 to 20.000
|
|
최소측정단위
|
0.1 pH; 0.01 pH; 0.001 pH
|
|
정확도
|
±0.1 pH; ±0.01 pH; ±0.002 pH
|
|
측정범위
|
mV
|
±2000 mV
|
|
최소측정단위
|
0.1 mV
|
|
정확도
|
±0.2 mV
|
|
측정범위
|
ISE
|
1 x 10 -7 to 9.99 x 1010 concentration
|
|
최소측정단위
|
1; 0.1; 0.01 concentration
|
|
정확도
|
±0.5% (monovalent ions);±1%
|
|
Factor
|
0.40 to 1.00
|
|
측정범위
|
EC
|
0.000 to 9.999 ㎲/cm; 10.00 to 99.99 ㎲/cm;
100.0 to 999.9 ㎲/cm; 1.000 to 9.999 mS/cm;
10.00 to 99.99 mS/cm; 100.0 to 999.9 mS/cm; 1000 mS/cm
|
|
최소측정단위
|
0.001 ㎲/cm; 0.01 ㎲/cm; 0.1 ㎲/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1 mS/cm; 1 mS/cm
|
|
정확도
|
±1% of reading (±0.01 S/cm)
|
|
측정범위
|
Resistivity
|
1.00 to 99.99 Ohm•cm; 100.0 to 999.9 Ohm•cm; 1.000 to 9.999 kOhm•cm; 10.00 to 99.99 kOhm•cm; 100.0 to 999.9 kOhm•cm; 1.00 to 9.99 Mohm•cm; 10.0 to 100.0 Mohm•cm
|
|
최소측정단위
|
0.01 Ohm•cm; 0.1 Ohm•cm; 0.001 kOhm•cm; 0.01 kOhm•cm; 0.1 kOhm•cm; 0.01 Mohm•cm; 0.1 Mohm•cm
|
|
정확도
|
±2% of reading (± 1Ohm•cm)
|
|
측정범위
|
TDS
|
0.000 to 9.999 ppm; 10.00 to 99.99 ppm; 100.0 to 999.9 ppm; 1.000 to 9.999 ppt; 10.00 to 99.99 ppt; 100.0 to 400.0 ppt
|
|
최소측정단위
|
0.001 ppm; 0.01 ppm; 0.1 ppm; 0.001 ppt; 0.01 ppt; 0.1 ppt
|
|
정확도
|
±1% of reading (±0.01 ppm)
|
|
요소
|
0.40 to 1.00
|
|
측정범위
|
염도
|
Practical Salinity: 0.00 to 42.00; Natural Seawater: 0.00 to 80.00 ppt; Percent: 0.0 to 400.0%
|
|
최소측정단위
|
0.01 for practical salinity / natural sea water; 0.1% for percent scale
|
|
정확도
|
±1% of reading
|
|
측정범위
|
온도
|
-20.0 to 120℃; -4.0 to 248.0℉; 253.15 to 393.15K
|
|
최소측정단위
|
0.1℃; 0.1℉; 0.1K
|
|
정확도
|
±0.2℃; ±0.4℉; ±0.2K
|
|
보정
|
pH
|
Automatic up to 5 points with 8 memorized values
(pH 1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45) + 5 custom buffers
|
|
ISE
|
Automatic up to 5 points with 6 standard + 5 custom values
|
|
EC
|
Auto standard recognition, custom calibration solution / 4 point calibration
|
|
염도
|
Percent scale -- 1 point (with HI 7037 buffer)
|
|
Temp
|
3 points
|
|
Relative mV Offset Range
|
±2000 mV
|
|
Input Channel(s)
|
1 pH/mV/ISE + 1 EC
|
|
보정확인
|
pH 전극과 버퍼상태
|
|
Temp 보정 (pH)
|
자동 또는 수동 -20.0 to 120.0℃
|
|
Temp 보정 (EC)
|
Linear and non-linear (natural water)
|
|
Log-on-demand
|
10 Lots, 5000 samples per lot
|
|
Auto Endpoint
|
Yes
|
|
PC Connection
|
Opto-isolated USB and RS232
|
|
Display
|
240 x 320 dot-matrix color LCD with on-screen help, graphing, language selection and custom configuration
|
|
Power
|
12 VDC adapter (included)
|
